Howo Tipper Trucks For Sale In Nigeria

New | Left hand drive | Automatic

howo tipper trucks for sale in nigeria-3

howo tipper trucks for sale in nigeria-2

howo tipper trucks for sale in nigeria-4

Truck Model: ZZ3257N3847A

Drive type:

6x4

Engine:

WD615.47, Euro 2

Fuel Tank:

300L

Horsepower:

371 HP

Overall Dimension:

8500*2550*3450mm

Net unit price, Nigeria,without VAT, subject to availability / prior sale.

Quotation request Contact us

Vehicle overview

This Howo Tipper Trucks For Sale 6×4 specifically designed to meet the diverse needs of Nigeria. Its robust construction ensures durability even on the country’s challenging terrains, from rugged mountains to muddy logging roads.

Powered by a high – performance engine, it offers excellent torque and horsepower, enabling efficient transportation of heavy loads. The large – capacity dump body can handle substantial volumes of materials such as construction aggregates, mining ores, or soil.

Technical Specifications

Chassis Model	ZZ3257N3847A
Driving Type	LHD (RHD is optional)
Cabin	HW76, with one sleeper and one seat, double arm windscreen wiper system with three speeds, damped adjustable driver’s seat, with heating and ventilating system, exterior sun visor, safety belts, adjustable steering wheel, air horn, air conditioner, with transverse stabilizer, with four piont support floating suspension+shock absorber.
Engine	Make: SINOTRUK Diesel 4-stroke direct injection diesel engine Engine model: WD615.47, Euro 2, 371 HP 6-cylinder in-line with water cooling, turbo-charging and intercooling Displacement: 9.726 L
Transmission	HW19710, 10F & 2R, with PTO Ratio:14.28, 10.62, 7.87, 5.88, 4.38, 3.27, 2.43, 1.80, 1.34, 1.00, 13.91(R1), 3.18(R2)
Steering	ZF power steering, modol ZF8118, hydraulic steering with power assitance
Front Axle	HF9,1×9000 KGS Steering with doubleT-cross section beam
Rear Axle	HC16, 2×16000 KGS Pressed axle housing, central single reduction with hub reduction,with differential locks between wheels and axles. Ratio:5.73
Propeller Shaft	Double universal joint propeller shaft with gear-shaped coupling flange
Chassis	Frame: Uprofile parallel ladder frame with section of 300x80x8mm,reinforced subframe all cold riveted cross members Front suspension:10 semi elliptic leaf spring, hydraulic telescopic double-action shock absorbers and stabilizer Rear suspension:12 leaf semi elliptic springs, bogie spring and stabilizer
Brake	Service brake: dual circuit compressed air brake Parking brake (emergency brake): spring energy, compressed air operating on front shaft and rear wheels Auxiliary brake: engine exhaust brake
Electrics	Operating voltage: 24 V, negative grounded Starter: 24 V, 5.4 Kw Alternator: 3-phase, 28 V, 1500 W Batteries: 2 x 12 V, 165 Ah Cigar-lighter, horn, headlamps, fog lights, brake lights, indicators and reverse light
Tyres	12.00R20, radial tyres with one spare tyre
Fuel Tank	300L
Cargo Body	580023001500 mm, 20 CBM, Floor 8mm Side 6mm
Overall Dimension	850025503450mm
